Technical Specification

PERFORMANCE

Processor            Intel Core i7-13700HX, 16C (8P + 8E) / 24T, P-core up to 5.0GHz, E-core up to 3.7GHz, 30MB 13th gen

Graphics              NVIDIA GeForce RTX 4070 8GB GDDR6, Boost Clock 2175MHz, TGP 140W

Chipset Intel HM770 Chipset

Memory              2x 8GB SO-DIMM DDR5-4800

Memory Slots    Two DDR5 SO-DIMM slots, dual-channel capable

Max Memory     Up to 32GB DDR5-4800 offering

Storage                1TB SSD M.2 2280 PCIe 4.0×4 NVMe

Storage Support               Up to two drives, 2x M.2 SSD / M.2 2280 SSD up to 1TB

Storage Slot        Two M.2 2280 PCIe 4.0 x4 slots

Card Reader       None

Optical                  None

Audio Chip          High Definition (HD) Audio, Realtek ALC3306 codec

Speakers             Stereo speakers, 2W x2, optimized with Nahimic Audio

Camera                FHD 1080p with E-shutter

Microphone       2x, Array

Battery Integrated 80Wh

Max Battery Life               MobileMark 2018: 5.3 hr

Local video (1080p) playback@150nits: 6.5 hr

Power Adapter 300W Slim Tip (3-pin)

Special Features               AI Chip: LA1

Legion Coldfront 5.0 cooling system

DESIGN

Display  16inch WQXGA (2560×1600) IPS 500nits Anti-glare, 100% sRGB, 240Hz, DisplayHDR 400, Dolby Vision, G-SYNC, Low Blue Light, High Gaming Performance

Touchscreen      None

Color Calibration               Factory Color Calibration

Keyboard            4-Zone RGB Backlit, English

Case Color           Onyx Grey

Surface Treatment          Anodizing

Case Material     Aluminium (Top), PC-ABS (Bottom)

Dimensions (WxDxH)     363.4 x 260.35 x 22.45-26.75 mm (14.31 x 10.25 x 0.88-1.05 inches)

Weight Less than 2.55 kg (5.6 lbs)

SOFTWARE

Operating System            Windows 11 Home Single Language, English

Bundled Software            Office Home & Student 2021

CONNECTIVITY

Ethernet              100/1000M (RJ-45)

WLAN + Bluetooth           Wi-Fi 6E, 11ax 2×2 + BT5.1

Standard Ports
3x USB 3.2 Gen 1
1x USB 3.2 Gen 1 (Always On)
1x USB-C 3.2 Gen 2 (support data transfer and DisplayPort 1.4)
1x USB-C 3.2 Gen 2 (support data transfer, Power Delivery 140W and DisplayPort 1.4)
1x HDMI, up to 8K/60Hz
1x Ethernet (RJ-45)
1x Headphone / microphone combo jack (3.5mm)
1x Power connector

Security Chip
Firmware TPM 2.0
Fingerprint Reader

Other Security   E-shutter

SERVICE

Base Warranty   1-year, Courier or Carry-in

ACCESSORIES

Bundled Accessories

Lenovo Legion M300 RGB Gaming Mouse

CERTIFICATIONS

Green Certifications
ErP Lot 3
RoHS compliant

Other Certifications
TÜV Rheinland High Gaming Performance
TÜV Rheinland Low Blue Light (Hardware Solution)
