Technical Specification

Processor:  AMD Ryzen 5 5600H (6C / 12T, 3.3 / 4.2GHz, 3MB L2 / 16MB L3)

Graphics:  NVIDIA GeForce RTX 3060 6GB GDDR6, Boost Clock 1282 / 1485MH, TGP 90W

Chipset:  AMD SoC Platform

Memory:  1x 8GB SO-DIMM DDR4-3200

Memory Slots:  Two DDR4 SO-DIMM slots, dual-channel capable

Max Memory:  Up to 16GB DDR4-3200 offering

Storage:  512GB SSD M.2 2280 PCIe 3.0×4 NVMe

Storage Support:  Model with RTX 3060: up to two drives, 2x M.2 SSD  M.2 2242 SSD up to

512GB  M.2 2280 SSD up to 1TB

Card Reader:  None

Optical:  None

Audio Chip:  High Definition (HD) Audio, Realtek ALC3287 codec

Speakers:  Stereo speakers, 2W x2, Nahimic Audio

Camera:  720p with Camera Shutter

Microphone:  2x, Array

Battery:  Integrated 60Wh

Max Battery Life:  MobileMark 2018: 7 hr (60Wh)

Power Adapter:  170W Slim Tip (3-pin)

DESIGN

Display:  15.6″ FHD (1920×1080) IPS 250nits Anti-glare, 120Hz, 45% NTSC, DC dimmer

Touchscreen:  None

Keyboard:  4-Zone RGB Backlit, English

Case Color:  Shadow Black

Surface Treatment:  IMR (In-Mold Decoration by Roller)

Case Material:  PC + ABS (Top), PC + ABS (Bottom)

Dimensions (WxDxH):  359.6 x 251.9 x 24.2 mm (14.16 x 9.92 x 0.95 inches)

Weight:  2.25 kg (4.96 lbs)

Operating System:  Windows 11 Home 64, English

CONNECTIVITY

Ethernet 100/1000M

WLAN + Bluetooth Wi-Fi 6 11ax, 2×2 + BT5.0

Standard Ports

2x USB 3.2 Gen 1

1x USB-C 3.2 Gen 1 (support data transfer only)

1x HDMI 2.0

1x Ethernet (RJ-45)

1x Headphone / microphone combo jack (3.5mm)

1x Power connector
