DJI Mic Mini 2 Transmitter

DMMT02

28.58×28.04×13.52 mm (L×W×H)

Approx. 11 g (excluding the magnet clip and magnet)

GFSK 2Mbps

< 20 dBm

2.400-2.4835 GHz

Bluetooth 5.3

2.400-2.4835 GHz

< 20 dBm

Li-ion

114 mAh

0.45 Wh

3.87 V

Max 5 V

5° to 45° C (41° to 113° F)

-10° to 45° C (14° to 113° F)

Approx. 70 minutes

Approx. 11.5 hours

Measured using DJI Mic Mini 2 (2 TX + 1 RX), with noise cancellation off, during close-range audio recording under interference-free conditions, with the transmitter connected to the receiver and the receiver connected to a camera via the Camera Audio Cable (3.5mm TRS).

DMMR01

46.50×29.61×19.32 mm (L×W×H)

Approx. 17.8 g (including the interface cover)

GFSK 2Mbps

< 20 dBm

2.400-2.4835 GHz

Bluetooth 5.3

< 20 dBm

2.400-2.4835 GHz

Li-ion

170 mAh

0.66 Wh

3.87 V

Max 5 V

5° to 45° C (41° to 113° F)

-10° to 45° C (14° to 113° F)

Approx. 100 minutes

Approx. 10.5 hours

Measured using DJI Mic Mini 2 (2 TX + 1 RX), with noise cancellation off, during close-range audio recording under interference-free conditions, with the transmitter connected to the receiver and the receiver connected to a camera via the Camera Audio Cable (3.5mm TRS).

DMMC02

106.30×42.50×59.20 mm (L×W×H)

Approx. 159.3 g (charging case only)

Li-ion

1950 mAh

7.55 Wh

3.87 V

Max 5 V, 3 A

5° to 40° C (41° to 104° F)

5° to 45° C (41° to 113° F)

Approx. 2 hours

When charging two transmitters and one receiver simultaneously, a fully charged charging case can fully charge them for approx. 3.6 times.

DMMR02

39.26×27.26×8.97 mm (L×W×H)

Approx. 6.5 g

GFSK 2Mbps

< 20 dBm

2.400-2.4835 GHz

Bluetooth 5.3

< 20 dBm

2.400-2.4835 GHz

5° to 45° C (41° to 113° F)

-10° to 45° C (14° to 113° F)

DMMCS2

78.8×33.07×44.70 mm (L×W×H)

Approx. 71.0 g (charging case only)

Li-ion

275 mAh

1.07 Wh

3.87 V

Max 5 V, 3 A

5° to 40° C (41° to 104° F)

5° to 45° C (41° to 113° F)

Approx. 1 hour

Approx. 1.3 cycles when charging one TX

Omnidirectional

Low Cut Off: 20 Hz – 20 kHz
Low Cut On: 100 Hz – 20 kHz

120 dB SPL@1% THD

–

24 dBA

20 mW@1 kHz, 32 Ω (DJI Mic Series Mobile Receiver)

400 m*

300 m**

200 m***

* When used with the DJI Mic Mini Receiver in DJI Mic Mini 2 (2 TX + 1 RX), transmission distance can reach up to 400 m in open, unobstructed, interference-free environments.
** When used with the DJI Mic Series Mobile Receiver in green light mode with two DJI Mic Mini 2 or two DJI Mic Mini transmitters, transmission distance can reach up to 300 m in open, unobstructed, interference-free environments.
*** When used with the DJI Mic Series Mobile Receiver in blue light mode, mixing any two from DJI Mic Mini 2, DJI Mic 3, DJI Mic Mini, or DJI Mic 2 transmitters, transmission distance can reach up to 200 m in open, unobstructed, interference-free environments.
